| Hardware | |
| Interface | – 2 *100Mbps LAN Ports
– 1 *100Mbps WAN Port |
| Power Supply | – DC 5V /0.6A |
| Button | – 1 *RST/WPS Button |
| LED Indicator | – 1* System, 1* Wi-Fi, 1* WAN, 2* LAN |
| Antenna | – 2 * external fixed antennas (2.4G) |
| Dimensions (L x W x H) | – 91mm *80mm *25mm |
| Wireless | |||||
| Standards | – IEEE 802.11b,
– IEEE 802.11g, – IEEE 802.11n |
||||
| RF Frequency | – 2.4~2.4835GHz | ||||
| Data Rate | – 2.4GHz: Up to 300Mbps | ||||
| EIRP | – < 20dBm | ||||
| Wireless Security | – WPA/WPA2 Mixed | ||||
| Reception Sensitivity | – 11b 11M：-85dBm@8% PER
11g 54M：-72dBm@10% PER 11n HT20 MCS7：-68dBm@10% PER HT40 MCS7：-65dBm@10% PER |
||||
| Software | |
| Operation Mode | – Gateway Mode
– Repeater Mode – Bridge Mode – WISP Mode |
| Home | – Quick Setup
– Basic setup – Advanced setup – QR Code – LED – Logout – Reboot |
| Network | – WAN Setting
– LAN Setting – DDNS Setting – IPTV Setting – IPv6 Setting |
| WAN Type | – Static IP, DHCP, PPPoE/Russia PPPoE, PPTP/Russia PPTP, L2TP/Russia L2TP |
| Wireless | – Basic setup
– Guest Network(Multiple SSID) – Wireless Schedule – Access Control – Advanced setup |
| Parental Control | – Internet time control based on MAC |
| QoS | – Up/Down speed control on WAN,
– Bandwidth control based on IP address |
| Device management | – Static Route
– Routing Table – IP/MAC Binding |
| Security | – MAC Filtering
– IP/Port Filtering – URL Filtering |
| NAT | – Virtual Server(Port Forwarding)
– DMZ – VPN passthrough |
| Tools | – Upgrade Firmware
– Time Setup – Remote managemet – Password Settings – Reboot Schedule – System Log and so on |
| Others | |||||
| Package Contents | – A200RE_V5 Wireless Router *1
– Power Adapter *1 – Ethernet Cable *1 – Quick Installation Guide *1 |
||||
| Environment | – Operating Temperature: 0℃~50 ℃ (32 ℉~122℉)- Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉)
– Operating Humidity: 5%~95% non-condensing – Storage Humidity: 5%~95% non-condensing |
||||
